Ubuntu SSH Setup: Secure Remote Access in 10 Minutes

Installing SSH Server

sudo apt update
sudo apt install openssh-server -y

Verify It's Running

sudo systemctl status ssh
sudo systemctl enable ssh

Connect from Another Machine

# Basic connection
ssh user@server-ip

# Example
ssh ubuntu@192.168.1.100

Find your server's IP:

ip addr show | grep "inet " | grep -v 127.0.0.1

Generate Key Pair (on your local machine)

ssh-keygen -t ed25519 -C "your@email.com"
# Press Enter for defaults
# Set a passphrase (recommended)

This creates:

  • ~/.ssh/id_ed25519 (private key — never share)
  • ~/.ssh/id_ed25519.pub (public key — goes on server)

Copy Public Key to Server

ssh-copy-id -i ~/.ssh/id_ed25519.pub user@server-ip

Or manually:

# On server
mkdir -p ~/.ssh
echo "your-public-key-content" >> ~/.ssh/authorized_keys
chmod 700 ~/.ssh
chmod 600 ~/.ssh/authorized_keys

Test Key Auth

ssh user@server-ip
# Should connect without password (or with key passphrase only)

Harden SSH Configuration

Edit the SSH server config:

sudo nano /etc/ssh/sshd_config

Essential Changes

# Change default port (optional, reduces bot scans)
Port 2222

# Disable root login
PermitRootLogin no

# Disable password authentication (keys only)
PasswordAuthentication no

# Disable empty passwords
PermitEmptyPasswords no

# Limit authentication attempts
MaxAuthTries 3

# Use only SSH protocol 2
Protocol 2

# Disable X11 forwarding (unless needed)
X11Forwarding no

# Set idle timeout (seconds)
ClientAliveInterval 300
ClientAliveCountMax 2

# Allow specific users only
AllowUsers ubuntu deploy

# Disable agent forwarding (unless needed)
AllowAgentForwarding no

Apply Changes

sudo sshd -t           # Test config syntax
sudo systemctl restart ssh

IMPORTANT: Before restarting, keep your current SSH session open. Test a new connection in a separate terminal to verify you can still connect.

UFW Firewall Rules

# Allow SSH (adjust port if changed)
sudo ufw allow 2222/tcp
# Or allow from specific IP only
sudo ufw allow from 203.0.113.50 to any port 2222

# Enable firewall
sudo ufw enable
sudo ufw status verbose

SSH Config File (Client Side)

Create ~/.ssh/config on your local machine:

Host myserver
    HostName 192.168.1.100
    User ubuntu
    Port 2222
    IdentityFile ~/.ssh/id_ed25519
    ServerAliveInterval 60

Now connect with just:

ssh myserver

SSH Tunnels (Port Forwarding)

Local Forward Access Remote Service Locally

# Access remote PostgreSQL locally
ssh -L 5432:localhost:5432 user@server

# Now connect to localhost:5432 to reach remote DB
psql -h localhost -p 5432

Remote Forward Expose Local Service

# Expose local dev server (port 3000) on remote (port 8080)
ssh -R 8080:localhost:3000 user@server

Dynamic Forward (SOCKS Proxy)

ssh -D 1080 user@server
# Configure browser to use SOCKS5 proxy at localhost:1080

SCP / File Transfer

# Upload file
scp ./file.txt user@server:/home/ubuntu/

# Download file
scp user@server:/var/log/syslog ./

# Upload directory (recursive)
scp -r ./project/ user@server:/home/ubuntu/project/

# Using config alias
scp ./file.txt myserver:/home/ubuntu/

rsync (Better for Directories)

# Sync directory to server
rsync -avz ./project/ myserver:/home/ubuntu/project/

# Exclude patterns
rsync -avz --exclude 'node_modules' --exclude '.git' ./project/ myserver:/home/ubuntu/project/

# Dry run first
rsync -avzn ./project/ myserver:/home/ubuntu/project/

Troubleshooting

Permission Denied (publickey)

# On server, check permissions
chmod 700 ~/.ssh
chmod 600 ~/.ssh/authorized_keys

# Check SSH logs
sudo journalctl -u ssh -f

Connection Refused

# Check if SSH is running
sudo systemctl status ssh

# Check if firewall is blocking
sudo ufw status

# Check if port is listening
sudo ss -tlnp | grep ssh

Slow Connection

Add to /etc/ssh/sshd_config:

UseDNS no
GSSAPIAuthentication no

SSH Key Management

List Keys

ls -la ~/.ssh/

Remove Old Keys from Server

# Edit authorized_keys and remove the line
nano ~/.ssh/authorized_keys

Rotate Keys

  1. Generate new key pair
  2. Copy new key to server
  3. Test new key works
  4. Remove old key from server
  5. Delete old private key
